| Type | High Temperature Cables |
| Series | SC 600 C HDTR |
| Gauge/c | 19 AWG (≈ 23/32)/5c |
| Color Code | HD 308 |
| Shielding | Tinned Braid Shield |
| Jacket | Black Besilen (similar to RAL 9011) |
| Approvals | UR AWM, CSA AWM, CE, EAC, RoHS |
| Voltage | 600 |
| Temperature Range | -40°C to +180°C; +200°C (2000h); +250°C (short-term use); UL/CSA: up to +150°C Style 4545 |
| View PDF For Complete Technical Specifications |
| Type | High Temperature Cables |
| Series | SC 600 C HDTR |
| Gauge/c | 18 AWG (≈ 30/32)/2c |
| Color Code | HD 308 |
| Shielding | Tinned Braid Shield |
| Jacket | Black Besilen (similar to RAL 9011) |
| Approvals | UR AWM, CSA AWM, CE, EAC, RoHS |
| Voltage | 600 |
| Temperature Range | -40°C to +180°C; +200°C (2000h); +250°C (short-term use); UL/CSA: up to +150°C Style 4548 |
| View PDF For Complete Technical Specifications |
| Type | High Temperature Cables |
| Series | SC 600 C HDTR |
| Gauge/c | 18 AWG (≈ 30/32)/3c |
| Color Code | HD 308 |
| Shielding | Tinned Braid Shield |
| Jacket | Black Besilen (similar to RAL 9011) |
| Approvals | UR AWM, CSA AWM, CE, EAC, RoHS |
| Voltage | 600 |
| Temperature Range | -40°C to +180°C; +200°C (2000h); +250°C (short-term use); UL/CSA: up to +150°C Style 4551 |
| View PDF For Complete Technical Specifications |
| Type | High Temperature Cables |
| Series | SC 600 C HDTR |
| Gauge/c | 18 AWG (≈ 30/32)/4c |
| Color Code | HD 308 |
| Shielding | Tinned Braid Shield |
| Jacket | Black Besilen (similar to RAL 9011) |
| Approvals | UR AWM, CSA AWM, CE, EAC, RoHS |
| Voltage | 600 |
| Temperature Range | -40°C to +180°C; +200°C (2000h); +250°C (short-term use); UL/CSA: up to +150°C Style 4554 |
| View PDF For Complete Technical Specifications |
| Type | High Temperature Cables |
| Series | SC 600 C HDTR |
| Gauge/c | 18 AWG (≈ 30/32)/5c |
| Color Code | HD 308 |
| Shielding | Tinned Braid Shield |
| Jacket | Black Besilen (similar to RAL 9011) |
| Approvals | UR AWM, CSA AWM, CE, EAC, RoHS |
| Voltage | 600 |
| Temperature Range | -40°C to +180°C; +200°C (2000h); +250°C (short-term use); UL/CSA: up to +150°C Style 4557 |
| View PDF For Complete Technical Specifications |
| Type | High Temperature Cables |
| Series | SC 600 C HDTR |
| Gauge/c | 18 AWG (≈ 30/32)/7c |
| Color Code | Black #'d plus ground |
| Shielding | Tinned Braid Shield |
| Jacket | Black Besilen (similar to RAL 9011) |
| Approvals | UR AWM, CSA AWM, CE, EAC, RoHS |
| Voltage | 600 |
| Temperature Range | -40°C to +180°C; +200°C (2000h); +250°C (short-term use); UL/CSA: up to +150°C Style 4560 |
| View PDF For Complete Technical Specifications |
| Type | High Temperature Cables |
| Series | SC 600 C HDTR |
| Gauge/c | 16 AWG (≈ 27-29/30)/2c |
| Color Code | HD 308 |
| Shielding | Tinned Braid Shield |
| Jacket | Black Besilen (similar to RAL 9011) |
| Approvals | UR AWM, CSA AWM, CE, EAC, RoHS |
| Voltage | 600 |
| Temperature Range | -40°C to +180°C; +200°C (2000h); +250°C (short-term use); UL/CSA: up to +150°C Style 4563 |
| View PDF For Complete Technical Specifications |
| Type | High Temperature Cables |
| Series | SC 600 C HDTR |
| Gauge/c | 16 AWG (≈ 27-29/30)/3c |
| Color Code | HD 308 |
| Shielding | Tinned Braid Shield |
| Jacket | Black Besilen (similar to RAL 9011) |
| Approvals | UR AWM, CSA AWM, CE, EAC, RoHS |
| Voltage | 600 |
| Temperature Range | -40°C to +180°C; +200°C (2000h); +250°C (short-term use); UL/CSA: up to +150°C Style 4566 |
| View PDF For Complete Technical Specifications |
| Type | High Temperature Cables |
| Series | SC 600 C HDTR |
| Gauge/c | 16 AWG (≈ 27-29/30)/4c |
| Color Code | HD 308 |
| Shielding | Tinned Braid Shield |
| Jacket | Black Besilen (similar to RAL 9011) |
| Approvals | UR AWM, CSA AWM, CE, EAC, RoHS |
| Voltage | 600 |
| Temperature Range | -40°C to +180°C; +200°C (2000h); +250°C (short-term use); UL/CSA: up to +150°C Style 4569 |
| View PDF For Complete Technical Specifications |
| Type | High Temperature Cables |
| Series | SC 600 C HDTR |
| Gauge/c | 16 AWG (≈ 27-29/30)/5c |
| Color Code | HD 308 |
| Shielding | Tinned Braid Shield |
| Jacket | Black Besilen (similar to RAL 9011) |
| Approvals | UR AWM, CSA AWM, CE, EAC, RoHS |
| Voltage | 600 |
| Temperature Range | -40°C to +180°C; +200°C (2000h); +250°C (short-term use); UL/CSA: up to +150°C Style 4572 |
| View PDF For Complete Technical Specifications |
| Type | High Temperature Cables |
| Series | SC 600 C HDTR |
| Gauge/c | 16 AWG (≈ 27-29/30)/7c |
| Color Code | Black #'d plus ground |
| Shielding | Tinned Braid Shield |
| Jacket | Black Besilen (similar to RAL 9011) |
| Approvals | UR AWM, CSA AWM, CE, EAC, RoHS |
| Voltage | 600 |
| Temperature Range | -40°C to +180°C; +200°C (2000h); +250°C (short-term use); UL/CSA: up to +150°C Style 4575 |
| View PDF For Complete Technical Specifications |
| Type | High Temperature Cables |
| Series | SC 600 C HDTR |
| Gauge/c | 14 AWG (≈ 46/30)/2c |
| Color Code | HD 308 |
| Shielding | Tinned Braid Shield |
| Jacket | Black Besilen (similar to RAL 9011) |
| Approvals | UR AWM, CSA AWM, CE, EAC, RoHS |
| Voltage | 600 |
| Temperature Range | -40°C to +180°C; +200°C (2000h); +250°C (short-term use); UL/CSA: up to +150°C Style 4578 |
| View PDF For Complete Technical Specifications |
