| Type | Reeling, Lift and Specialty Cables |
| Series | GP 400 QF |
| Gauge/c | 4 x (2 AWG + 4 x18 AWG) |
| Color Code |
control conductors: red, black, green, yellow; power supply conductors: red |
| Jacket | Orange PUR |
| Approvals | CE, EAC, RoHS |
| Temperature Range | -50°C to +90°C; short-term use: +110°C (7,500 h) |
| View PDF For Complete Technical Specifications |
| Type | Reeling, Lift and Specialty Cables |
| Series | GP 400 QF |
| Gauge/c | 4 x (2/0 AWG + 4 x18 AWG) |
| Color Code |
control conductors: red, black, green, yellow; power supply conductors: red |
| Jacket | Orange PUR |
| Approvals | CE, EAC, RoHS |
| Temperature Range | -50°C to +90°C; short-term use: +110°C (7,500 h) |
| View PDF For Complete Technical Specifications |
| Type | Reeling, Lift and Specialty Cables |
| Series | GP 400 SF |
| Gauge/c | 7 x 4 AWG + (6x3 x 18 AWG) |
| Color Code |
control conductors: black with numbers 1 - 18; neutral conductor: blue; phase conductor: white, brown, black (two conductors of the same color for the phase) |
| Jacket | Orange Special Compound |
| Approvals | CE, EAC, RoHS |
| Temperature Range | -40°C to +70°C |
| View PDF For Complete Technical Specifications |
| Type | Reeling, Lift and Specialty Cables |
| Series | GP 400 SF |
| Gauge/c | 7 x 2AWG + (6x3 x 18 AWG) |
| Color Code |
control conductors: black with numbers 1 - 18; neutral conductor: blue; phase conductor: white, brown, black (two conductors of the same color for the phase) |
| Jacket | Orange Special Compound |
| Approvals | CE, EAC, RoHS |
| Temperature Range | -40°C to +70°C |
| View PDF For Complete Technical Specifications |
| Type | Reeling, Lift and Specialty Cables |
| Series | GP 400 SF DR |
| Gauge/c | 7 x 2 AWG + (6x4 x 18 AWG) |
| Color Code |
control conductors: black with numbers 1 - 24; neutral conductor: blue; phase conductor: white, brown, black; (two conductors of the same color for the phase) |
| Jacket | Orange PUR |
| Approvals | CE, EAC, RoHS |
| Temperature Range | -50°C to +90°C |
| View PDF For Complete Technical Specifications |
| Type | Reeling, Lift and Specialty Cables |
| Series | CAN-BUS Hybrid |
| Gauge/c | 2 x 2 x 20 AWG + 4 x 20 AWG + 2 x 20 AWG |
| Shielding | Tinned Braid Shield |
| Jacket | Black SABIX (RAL 9005) |
| Approvals | CE, EAC, RoHS |
| Temperature Range | -40°C to +70°C |
| View PDF For Complete Technical Specifications |
| Type | Reeling, Lift and Specialty Cables |
| Series | Profibus-DP cable with valve control |
| Gauge/c | 22 AWG/2c + 16 AWG/4c |
| Shielding | Tinned Braid Shield |
| Jacket | Red Lilac TMPU (RAL 4001) |
| Approvals | CE, EAC, RoHS |
| Temperature Range | -40°C to +80°C |
| View PDF For Complete Technical Specifications |
| Type | Torsion Cables |
| Series | Profibus-DP cable with current supply |
| Gauge/c | 2 x 22 AWG + 3 x 18 AWG |
| Shielding | Tinned Braid Shield |
| Jacket | Red Lilac TMPU (RAL 4001) |
| Approvals | CE, EAC, RoHS |
| Temperature Range | -40°C to +80°C |
| View PDF For Complete Technical Specifications |
| Type | Reeling, Lift and Specialty Cables |
| Series | Coupling cable T 790 |
| Gauge/c | 33 x 16 AWG + 3 x 8 AWG + 4 x (2 x 16 AWG) |
| Shielding | Tinned Braid Shield |
| Jacket | Black Special PUR (RAL 9005) |
| Approvals | CE, RoHS |
| Temperature Range | -50°C to +90°C |
| View PDF For Complete Technical Specifications |
| Type | Reeling, Lift and Specialty Cables |
| Series | Flexible PUR Interbus Hybrid |
| Gauge/c | 4 x 18 AWG + 5 x 2 x 24 AWG + 1 x 18 AWG |
| Color Code | 24 AWG: DIN 47100, see page O/26; 18 AWG: black, blue, red, brown, green/yellow |
| Shielding | Tinned Braid Shield |
| Jacket | Red Lilac Special PUR (RAL 4001) |
| Approvals | CE, EAC, RoHS |
| Temperature Range | -40°C to +70°C |
| View PDF For Complete Technical Specifications |
| Type | Reeling, Lift and Specialty Cables |
| Series | PVC Interbus Hybrid |
| Gauge/c | 4 x 18 AWG + 5 x 2 x 24 AWG + 1 x 18 AWG |
| Color Code | 24 AWG: DIN 47100, see page O/26; 18 AWG: black, blue, red, brown, green/yellow |
| Shielding | Tinned Braid Shield |
| Jacket | Red Lilac PVC (RAL 4001) |
| Approvals | CE, EAC, RoHS |
| Temperature Range | -5°C to +70°C |
| View PDF For Complete Technical Specifications |
| Type | Reeling, Lift and Specialty Cables |
| Series | Hybrid control cable for flexing applications |
| Gauge/c | 23 x 18 AWG + (2 x 18 AWG) D |
| Color Code | white conductors with consecutive numbers acc. to EN 50334 + VDE 0293-334 and a green/yellow ground |
| Shielding | Tinned Braid Shield |
| Jacket | Black Special PUR (RAL 9005) |
| Approvals | CE, RoHS |
| Temperature Range | -50°C to +90°C |
| View PDF For Complete Technical Specifications |
