Filter Cord Grip Selection
EXM2-75-TL9
Category: Explosion Proof Cable Glands
| Type | EX e |
| Thread | M75x1.5 |
| Series | EX EMC-2 Metric EX e |
| Description | EX e EMC-2 Nickel plated brass EX e E grounding and explosion proof cable gland, M75 |
| Material | Nickel Plated Brass |
| Temp Range (Permanent) | -40°C to +80°C |
| Approvals | UL, ATEX, IECEx, EAC, IN Metro, DNV |
| Clamping Range | 1.811 - 2.441 in. (46.0 - 62.0 mm) |
| Thread Diameter | 2.953 in. (75 mm) |
| Wrenching Flats | 0.787 in. (20 mm) Cap / 3.150 in. (80 mm) Body |
| Thread Length | 0.354 in. (9 mm) |
| Height (in) | 2.087 |
| Height (mm) | 53.0 |
| Product Datasheet |
 |
